AsteRx SB3 Sx

 DOWNLOAD


The AsteRx SB3 Sx is a compact, high performance  housed GNSS receiver ideal for integration into  demanding industrial applications where power  and space are at a premium. It delivers out-of-the  box sub-decimeter accuracy thanks to the built-in  PPP-RTK (a.k.a. SSR) correction service that will be  active for a five-year period.


KEY FEATURES

* All in view, multi-constellation, multi-frequency  satellite tracking

* Sub-degree GNSS heading & pitch or heading & roll

* AIM+ Interference monitoring and mitigation  function

* Sub-decimeter accuracy out of the box, with no additional service subscription required

* Five-year PPP-RTK corrections included

* Compact, yet rugged design


Plug-and-play sub-decimeter accuracy

 The AsteRx SB3 Sx offers plug-and-play sub-decimeter  accuracy enabled by the built-in PPP-RTK corrections. No  need for selecting, setting-up and maintaining any additional subscription services. PPP-RTK is the latest generation of  GNSS correction services, which uniquely combines near-RTK accuracy with quick convergence time.


Feature-rich in a compact design

Simultaneous multi-constellation, multi-frequency tracking  combined with the GNSS+ toolset and high-update rate,  low-latency output mean that AsteRx SB3 Sx is ideally suited  for any space-constrained industrial application under any  conditions.


Ease of integration

The AsteRx SB3 Sx integrates seamlessly into any system  thanks to fully documented interfaces, commands and data  messages. Septentrio’s open interfaces and software tools  (WebUI, RxTools) make it easy to the integrate, configurate  and control the AsteRx SB3 Sx.


FEATURES

GNSS signals

544 Hardware channels for simultaneous tracking  of most visible signals:

* GPS: L1 C/A, L1C, L2C, L2 P(Y), L5

* GLONASS: L1 C/A, L2C/A, L3, L2P

* BeiDou: B1I, B1C, B2a, B2I, B3I

* Galileo: E1, E5a, E5b

* QZSS: L1 C/A, L1C, L2C, L5

* NavIC: L5

* SBAS: EGNOS, WAAS, GAGAN, MSAS, SDCM


Septentrio’s patented GNSS+ technologies

* AIM+ unique anti-jamming and monitoring  system against narrow and wideband  interference

* APME+ a posteriori multipath estimator for  code and phase multipath mitigation

* LOCK+ superior tracking robustness under  heavy mechanical shocks or vibrations

* IONO+ advanced scintillation mitigation

* RAIM+ (Receiver Autonomous Integrity  Monitoring)

PPP-RTK corrections delivered via NTRIP or L-band in EU and USA


Formats

Septentrio Binary Format (SBF), fully documented  with sample parsing tools

 NMEA 0183, v3.01, v4.0

RTCM v2.x, v3.x (MSM messages included)

CMR v2.0 and CMR+ (CMR+ input only)


 Connectivity

3 Hi-speed serial ports (RS232)

Ethernet port (TCP/IP, UDP, LAN 10/100 Mbps)

Power over ethernet

1 High-speed/full-speed USB device port

2 Event markers

FTP server

16 GB internal memory


SUPPORTING COMPONENTS

Embedded Web UI with full control and  monitoring functionality.

RxTools, a complete and intuitive GUI tool set for  receiver control, monitoring, data analysis and  conversion.

GNSS receiver communication SDK. Available for  both Windows and Linux.


Optional accessories

* Antennas

* GeoTagZ re-processing software and SDK  library for UAS applications


PERFORMANCE

PPP-RTK performance

Horizontal accuracy                    <= 5 cm

Initialisation / convergence         <= 60 s

Coverage                               EU and USA


RTK performance 1,2,3

Horizontal accuracy     0.6 cm + 0.5 ppm

Vertical accuracy               1 cm + 1 ppm

Initialisation                                          7 s


GNSS attitude accuracy 1,2

Antenna separation   Heading   Pitch/Roll

1 m                                  0.15°          0.25°

5 m                                  0.03°         0.05°


Position accuracy 1,2

                           Horizontal          Vertical

Standalone                1.2 m              1.9 m

SBAS                          0.6 m             0.8 m

DGNSS                        0.4 m            0.7 m


Velocity accuracy 1,2                   0.03 m/s


Maximum update rate

Position                                          100 Hz

Measurements                               100 Hz


Latency 4                                       <10 ms


Time precision

xPPS out5                                           5 ns

Event accuracy                              < 20 ns


Time to first fix

Cold start6                                      < 45 s

Warm start7                                    < 20 s

Re-acquisition                              avg. 1 s


Tracking performance (C/N0 threshold)

Tracking                                     20 dB-Hz

Acquisition                                33 dB-Hz


PHYSICAL AND ENVIRONMENTAL

SWaP

Size                             102 x 36 x 118 mm

Weight                                             497 g

Input voltage                         5 to 36 VDC


Power consumption

GPS/GLO L1/L2                                 1.1 W

  All signals, all GNSS constellations

                                                        1.3 W


Connectors

Antenna                                       2 x TNC

ETH                                         ODU 4 pins

COM1/GPIO                           ODU 7 pins

PWR/USB/COM2/COM3        ODU 7 pins


Antenna LNA power output on TNC

Output voltage                              5 VDC

Maximum current                        200 mA


Environmental

Operating temperature  -30° C to +65° C

Storage temperature      -40° C to +75° C

Humidity       MIL-STD-810G, Method 507.5, Procedure I

Dust              MIL-STD-810G, Method 510.5, Procedure I

Shock           MIL-STD-810G, Method 516.6, Procedure I/II

Vibration      MIL-STD-810G, Method 514.6, Procedure I


Certification

IP 68, RoHS, WEEE, CE, ISO 9001-2015

FCC Class A Part 15

IEC 62368-1


1  Open sky conditions

2  RMS level

3  Baseline < 40 Km

4  99.9%

5  Including software compensation of sawtooth effect

6  No information available (no almanac, no approximate   position)

7  Ephemeris and approximate position known
